Part Number: STD820-E1HS4AS-1-A-AHB-11S-A-10A0Model: STD820 SmartLine Differential Pressure Transmitter
Brand: Honeywell
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months
Ordering Information
| Model | STD820 | Differential Pressure Transmitter |
| Process Wetted Heads & Diaphragm Materials | E | Process Head Material: 316 Stainless Steel
Diaphragm Material: 316L Stainless Steel |
| Fill Fluid | 1 | Silicone Oil 200 |
| Process Connection | H | 1/2" NPT female
Materials to Match Head & Head Bolt Materials Selections(1) |
| Bolt/Nuts Materials | S | 316 SS |
| Vent/Drain Type/Location | 4 | Head Type: Dual Ended
Vent Type: Standard Vent
Location: End
Vent Material: Matches Head Material(1) |
| Gasket Materials | A | Teflon® or PTFE (Glass Filled) |
| Static Pressure | S | Standard Static Pressure - 4500 psig (315 bar) |
| Head/Connect Orientation | 1 | Standard
High Side Left, Low Side Right(2) / Std Head Orientation |
| Approvals | A | FM Explosion proof, Intrinsically Safe, Non-incendive, & Dustproof |
| Electronic Housing Material & Connection Type | A | Material: Polyester Powder Coated Aluminum
Connection: 1/2 NPT
Lighting Protection: None |
| Output/Protocol | H | Analog Output: 4-20mA dc
Digital Protocol: HART Protocol |
| Customer Interface Selections | B | Indicator: Basic
Ext Zero, Span & Config Buttons: None
Languages: English |
| Application Software | 1 | Diagnostics: Standard Diagnostics |
| Output Limit, Failsafe & Write Protect Settings | 1 | Write Protect: Disabled
Fail Mode: High> 21.0mAdc
High & Low Output Limits(3): Honeywell Std (3.8 - 20.8 mAdc) |
| General Configuration | S | Factory Standard |
| Accuracy and Calibration | A | Accuracy: Standard
Calibrated Range: Factory Std
Calibration Qty: Single Calibration |
| Mounting Bracket | 1 | Bracket Type: Angle Bracket
Material: Carbon Steel |
| Customer Tag | 0 | No customer tag |
| Unassembled Conduit Plugs & Adapters | A0 | No Conduit Plugs or Adapters Required |
- Except Carbon Steel Heads shall use 316SS Vent/Drain, Plugs & Adapters when required
- Left side/Right side as view ed from the customer connection perspective
- NAMUR Output Limits 3.8 - 20.5mAdc can be configured by the customer or select custom configuration Table Vc
- Availability: In Stock
- Estimated Lead Time: Usually Ships in 7 - 10 Working Days
- Shipping Weight: 8 Kg
- Made in China
