Part Number: 50P15-ER0A1AA0BBAAModel: Proline Promag 50P Electromagnetic Flowmeter
Brand: Endress+Hauser
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months
Features & Specifications
| Measuring principle | Electromagnetic |
| Product headline | The flowmeter for highest medium temperatures with a modular electronic concept.
Dedicated to chemical and process applications with corrosive liquids and high medium temperatures. |
| Sensor features | Diverse applications ???wide variety of wetted materials. Energy-saving flow measurement ???no pressure loss due to cross section constriction. Maintenance-free ???no moving parts.
Nominal diameter: max. DN 600 (24"). All common Ex approvals. Liner made of PTFE or PFA. |
| Transmitter features | Quality ???designed for custody transfer; featuring worldwide recognized metrological approvals. Safe operation ???display provides easily readable process information. Fully industry-compliant ???IEC/EN/NAMUR.
2-line backlit display with push buttons. Device as compact or remote version. HART, PROFIBUS PA/DP. |
| Nominal diameter range | DN15...600
1/2"...24" |
| Max. measurement error | ±0.5%
±0.2% (optional) |
| Measuring range | 0...9'600 m3/h |
| Max. process pressure | PN10...40
Cl 150...300
JIS 10...20K
AS 2129 Table E
AS 4087 PN16 |
| Medium temperature range | -40...+180°C
(-40...+356°F) |
| Ambient temperature range | -20...+60°C
-40...+60°C (optional) |
| Degree of protection | IP 67 (NEMA 4x)
IP 68 (Nema 6P) |
| Display/Operation | Two line display with backlit
Push button |
| Outputs | 4...20 mA
Pulse/Frequency
Status |
| Inputs | Status |
| Digital communication | HART
PROFIBUS PA |
| Hazardous area approvals | ATEX, IECEx, NEPSI, FM, CSA |
| Product safety | CE, C-tick, EAC marking |
| Pressure approvals and certificates | PED, CRN |
- Estimated Lead Time: 6 - 8
- Shipping Weight: 8 Kg
