Home :: Rosemount Transmitter :: 3051S1TG2A2A11A1AB4M5 New Rosemount 3051S Scalable Pressure Transmitter

Product 356/1465

3051S1TG2A2A11A1AB4M5 New Rosemount 3051S Scalable Pressure Transmitter

$1,092.00 $689.00
Save: 37% off

Part Number: 3051S1TG2A2A11A1AB4M5

Model: 3051S Scalable Pressure Transmitter

Manufacturer: Rosemount

Specifications

Rangedown: Up to 200:1
Communication Protocol: 4-20 mA HART, WirelessHART®, FOUNDATION fieldbus
Measurement Range: Up to 2000psi (137,89 bar) Differential, Up to 2000psig (137,89 bar) Gage, Up to 4000psia (275,79 bar) Absolute
Process Wetted Material: 316L SST, Alloy C-276, Alloy 400, Tantalum, Gold-plated Alloy 400, Gold-plated 316L SST
Diagnostics: Basic Diagnostics, Loop Integrity, Process Intelligence, Plugged Impulse Line
Certifications/Approvals: SIL 2/3 certified to IEC 61508 by an independent 3rd party, NSF, NACE, hazardous location, see full specs for complete list of certifications3051S Scalable Pressure Transmitter

Features

Patented Rosemount Coplanar technology offers optimized performance as a pressure, DP Flow and DP Level solution
Best-in-class, scalable architecture enhances performance, functionality and process connections
Transmitter arrives fully assembled and leak tested for simple installation and maintenance
All-welded hermetic SST SuperModule platform resists overpressure and line pressure effects to ensure 0.025% accuracy
Ultra and Ultra for Flow performance classes deliver 15-year stability and 15-year limited warranty
200:1 rangedown produce reliable measurements and wide application flexibility
Integrates seamlessly with 4-20 mA HART®, WirelessHART®, FOUNDATION? fieldbus protocols for application flexibility
SIL 2/3 certified to IEC 61508 (via 3rd party) and prior-use certificate of FMEDA data for safety installations
Advanced diagnostics provide diagnostic coverage to detect electrical loop issues and abnormal process conditions
Remote display and interface offers easy access to process and device information

Add to Cart:
