| Model | 1771-P5E |
Module location
| 2 adjacent slots in a 1771 I/O chassis |
| Nominal Input Voltage/Current | 3.0A, 24V dc
|
| Input Voltage Range | 20.5 to 30V dc
|
| Input Power | 57 Watts
|
| Frequency Range | Not applicable |
| Isolation Voltage | Tested to 2160V dc for 1s |
| Output Voltage | 5.06 (?3.8%)V dc |
| Output Current | 8A @ 5V dc maximum |
| Fuse | 5A 32V normal blow
Bussman MTH5
Littlefuse 312005
IEC 127 Type M (yellow) |
Power Dissipation
| 4W maximum @ 2A
7W maximum @ 4A
12W maximum @ 6A
17W maximum @ 8A |
| Adjacent Slot Power Dissipation | 10W maximum |
Terminal Block Screw Torque
| 7 pound-inches (0.5Nm) |
Conductors
Wire Size:
Insulation Category: |
14AWG (2.5mm?) copper wire rated at 60?C or greater
3/64 inch (1.2mm) insulation maximum 2? |
| Branch Circuit Protection | 15A maximum, user supplied |
Power Loss Time Delay - Input
Power Loss to Processor Disable | Adjustable
13.6 (?3.6ms)ms or 60ms |
Environmental Conditions
Operating Temperature
|
IEC 60068-2-1 (Test Ad, Operating Cold)
IEC 60068-2-2 (Test Bd, Operating Dry Heat)
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
32 to 140? (0 to 60?C) |
| Storage Temperature | IEC 60068-2-1 (Test Ab, Unpackaged, Nonoperating Cold) IEC 60068-2-2 (Tested Bd, Unpackaged, Nonoperating Dry Heat) IEC 60068-2-14 (Tested Na, Unpackaged, Nonoperating Thermal Shock) -14 to 185?F (-40 to 85?C) |
| Relative Humidity | IEC 60068-2-30 (Test Db, Unpackaged, Nonoperating Damp Heat)
5 to 95%, noncondensing |
| Enclosure Type Rating | None (open-style)
|
| Weight | 2.6 lbs (1.18 kg) |
| Keying - right hand slot | between 12 and 14
between 22 and 24 |
| External Transformer (if used) | Not applicable |
