| Model | 1762-IQ8 |
Dimensions
| 90 mm (height) x 87 mm (depth) x 40 mm (width)
height including mounting tabs is 110 mm
3.543 in. (height) x 3.425 in. (depth) x 1.575 in. (width)
height including mounting tabs is 4.33 in. |
| Approximate Shipping Weight (with carton) | 200 g (0.44 lbs.) |
| Storage Temperature | -40?C to +85?C (-40?F to +185?F) |
| Operating Temperature | 0?C to +55?C (-32?F to +131?F) |
| Operating Humidity | 5% to 95% non-condensing |
| Operating Altitude | 2000 meters (6561 feet) |
Vibration | Operating: 10 to 500 Hz, 5G, 0.030 in. max. peak-to-peak |
| Shock | Operating: 30G panel mounted |
Agency Certification
| C-UL certified (under CSA C22.2 No. 142)
UL 508 listed
CE compliant for all applicable directives |
Hazardous Environment Class
| Class I, Division 2, Hazardous Location, Groups A, B, C, D
(UL 1604, C-UL under CSA C22.2 No. 213) |
| Noise Immunity | NEMA standard ICS 2-230 |
| Radiated and Conducted Emissions | EN50081-2 Class A |
| Electrical /EMC: | The module has passed testing at the following levels: |
| ESD Immunity (IEC1000-4-2) | 4 kV contact, 8 kV air, 4 kV indirect |
Radiated Immunity (IEC1000-4-3)
| 10 V/m, 80 to 1000 MHz, 80% amplitude modulation,
+900 MHz keyed carrier |
| Fast Transient Burst (IEC1000-4-4) | 2 kV, 5 kHz |
| Surge Immunity (IEC1000-4-5) | 2 kV common mode, 1 kV differential mode |
| Conducted Immunity (IEC1000-4-6) | 10V, 0.15 to 80 MHz? |
