Product Number: 1756-IB16Model: Digital DC Input Module
Manufacturer: Allen Bradley
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months
Technical Specifications
- Model: 1756-IB16
- Inputs: 16 (8 points/group)
- Voltage category: 12/24V DC sink
- Operating voltage range: 10 31.2V DC
- Input voltage, nom: 24V DC
- Input delay time (screw to backplane):
Off to On: Hardware delay: 290 s nom/1 ms max + filter time; User-selectable filter time: 0, 1, or 2 ms
On to Off: Hardware delay: 700 s nom/2 ms max + filter time; User-selectable filter time: 0, 1, 2, 9, or 18 ms - Current draw @ 5.1V: 100 mA
- Current draw @ 24V: 2 mA
- Total backplane power: 0.56 W
- Power dissipation, max: 5.1 W @ 60??C (140??F)
- Thermal dissipation: 17.39 BTU/hr
- Off-state voltage, max: 5V
- Off-state current, max: 1.5 mA
- On-state current, min: 2 mA @ 10V DC
- On-state current, max: 10 mA @ 31.2V DC
- Inrush current, max: 250 mA peak (decaying to < 37% in 22 ms, without activation)
- Input impedance, max: 3.12 k @ 31.2V DC
- Cyclic update time: 200 s 750 ms
- Change of state: Software configurable
- Timestamp of inputs: ?200 s
- Isolation voltage:
250V (continuous), basic insulation type, inputs-to-backplane, and input group-to-group
No isolation between individual group inputs
Routine tested @ 1350V AC for 2 s - Module keying: Electronic, software configurable
- RTB keying: User-defined mechanical
- Slot width: 1
- Wire category: 11
- North American temperature code: T3C
- IEC temperature code: T3
- Enclosure type: None (open-style)
- Reverse polarity protection: Yes
NOTE:
- Use this conductor category information for planning conductor routing as described in the system-level installation manual.
- Availability: In Stock
- Estimated Lead Time: Usually Ships in 1 - 7 Working Days
- Shipping Weight: 2 Kg
